VB4815D-15W
low ripple & noise dc-dc converter, 15W, 36~72V to 15V, 1500V isolated
- Input Voltage :
- 36~72V
- Output Voltage :
- 15V
- Output Power :
- 15W
- I/O Isolation :
- 1500V
- Output Regulation :
- Regulated
- Footprint Type :
- DIP
- No of Outputs :
- 1
| Model Name | input voltage | output voltage | output power | i/o isolation | output regulation | footprint type | |||
|---|---|---|---|---|---|---|---|---|---|
|
|
VB4824D-15W | 36~72V | 24V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB4815D-15W | 36~72V | 15V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB4812D-15W | 36~72V | 12V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB4809D-15W | 36~72V | 9V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB4805D-15W | 36~72V | 5V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB2424D-15W | 18~36V | 24V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB2415D-15W | 18~36V | 15V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB2412D-15W | 18~36V | 12V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB2409D-15W | 18~36V | 9V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB2405D-15W | 18~36V | 5V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB1224D-15W | 9~18V | 24V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB1215D-15W | 9~18V | 15V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB1212D-15W | 9~18V | 12V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB1209D-15W | 9~18V | 9V | 15W | 1500V | Regulated | DIP | 1 | see more |
|
|
VB1205D-15W | 9~18V | 5V | 15W | 1500V | Regulated | DIP | 1 | see more |
